CIMControl Framework GEM Interface Custom Message Handling

Posted by Lin Chen on Sep 5, 2023 4:21:00 PM

Process Recipe Management Custom Message Handling

Process Recipe Management provides a means to transfer process specifications and to share the management of these specifications between the host and the equipment. CCF provides GEM-compliant Process Recipe Management through class RecipeHandler which handles Steam 7 functions used for formatted and unformatted process programs. In some cases, CCF users may want to implement equipment-specific recipe handling, which can be done by extending the methods of RecipeHandler. For example, to customize host-initiated S7F5 for a recipe to be uploaded from the equipment, create a subclass MyRecipeHandler from RecipeHandler, and override the RecipeRequest method.

CCF-Custom-Msg-pic1

Follow this same approach to use the customized message handling class properly: before creating the FactoryAutomationServer, create a CimConnectServices and assign it to the CimConnectServices instance. Then create the custom message handling class MyRecipeHandler and assign it to the corresponding property on the CimConnectServices.Instance.

CCF-Custom-Msg-pic2

Custom SECS-II Message Handling

CCF provides a mechanism that enables the equipment’s GEM interface to support any SECS-II messages. These can be additional SECS-II messages defined in the SEMI E5 standard but not supported by CCF, and/or they can be custom SECS-II messages defined by and required by the end user or by the equipment supplier. For example, if a user wants to handle a custom message S100F1, they can create a subclass CustomMessageHandler and let it implement the IGemHandler interface, and then initialize it by overriding the Initialize method of CIMConnectServices.

CCF-Custom-Msg-pic3CCF-Custom-Msg-pic4CCF-Custom-Msg-pic5

To learn more about GEM interface custom message handling, please schedule a time to talk with a Cimetrix representative by clicking the button below.
